KS-7204-PN
NEW STOCK
$100
 |
Pan / Tilt / Zoom
Zoom Lens
IP Camera
CMOS
2048*1080
1080*1280
| Product Name | AI Smart Panel IP Camera (Face / Mask / Temperature Detection + Access Control / Attendance) |
| Model | KG-002 |
| Highlights | Support Temperature Measurement, Face and Mask Recognition, Access Control and Attendance, Identity Recognition and Access Management in various places with large crowd. |
| Product | Model | KG-002 |
| System | Main DSP processor | Hi3516CV500 |
| operating system | Embedded Linux operating system | |
| Video | Imaging Sensor | 1 / 2.8 Sony IMX327 |
| Video coding standard | H.264 / H.265 | |
| System format | PAL 50HZ / NTSC 60HZ | |
| Effective resolution | 1920 * 1080/1280 * 720 | |
| screen size | 7-inch LCD HD screen | |
| Video stream | 128kbps-12288kbps (default variable bit rate) | |
| Signal to noise ratio | Signal to noise ratio ≥69dB | |
| Minimum illumination | Daytime mode 1Lux, night vision mode 0.01Lux | |
| Day and night mode | Automatic (passive mode) / day / night / automatic (active mode) / timed | |
| AWB/ BLC / Gain AGC | AUTO Automatic White Balance, Backlight Compensation, Wide Dynamic | |
| AES | AUTO Automatic Electronic Shutter 1/50 (1/60) -1 / 100,000sec | |
| Video output | Easytool / EasyVMS client / mobile APP client / 7-inch LCD HD display | |
| Motion Detection | Support | |
| Snapshot function | Support | |
| Two-Way Audio Intercom | Coding standard | G.711U |
| Audio input | Passive microphone MIC / active pickup | |
| Audio output | External 8Ω / MAX 1.5W speaker | |
| Video Management | Recording method | Manual recording, alarm recording, timing recording |
| Video save | TF card (full function board) / PC terminal / NVR | |
| Alarm | Alarm input / output | Support Wiegand protocol |
| Alarm trigger | Motion detection alarm, speaker alarm, alarm recording, snapshot, email | |
| Network | Network protocol | HTTP, TCP / IP, IPV4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP |
| Other | Operating Voltage | Standard DC-12V (wide voltage 10-16V) |
| Working current | 160mA ± 10mA | |
| Working environment | 15 ºC to 30 ºC | |
| Weight and Size | Net Weight | 1.1kg |
| Gross Weight | 1.6kg | |
| Product Size | 367mm*95mm*120mm | |
| Gift Box Size | 445mm*175mm*135mm | |
| Quantity per CTN | 9pcs per CTNs | |
| CTN Size | 475mm*560mm*425mm |
Shenzhen Hankvision Technology Co.,Ltd. esteblished up in 2012, after 12 years development, now we become an AI video solution provider with cutting-edge technology and creative products. It has been certified with "SRDI" Enterprise (Specialized, Refinement, Differential and Innovation) in Guangdong, National High-tech and Shenzhen High-tech Enterprise.
