Hankvision Ai Thermal Imaging Camera 1080P Long Distance Human Body Temperature Measurement Integrated Machine with Black Body

Share to:

Hankvision Ai Thermal Imaging Camera 1080P Long Distance Human Body Temperature Measurement Integrated Machine with Black Body

5 0 Reviews

Price: $ 0

Discount Price: $ 0

Technology:
Pan / Tilt / Zoom
Style:
Zoom Lens
Type:
IP Camera
Sensor:
CMOS
HDMI Format:
2048*1080
Horizontal Resolution:
1080*1280

Availability:

Quantity:



Buy Now Add to Cart 12 0

Product Description

*The thermal imaging temperature measuring module has a pixel up to 256x192
*Pixel size 12μm, thermal sensitivity (NETD) : ≤60mK (@25ºC, F#=1.1)
* Non-contact personnel temperature measurement, accuracy: ±0.3ºC (target temperature 30ºC~50ºC)
* Human body temperature measurement distance: 1 m ~4 m
* Has a built-in 1080P visible image sensor
* Embedded deep learning algorithm can detect and measure temperature for 20 people at the same time
* Max output frame rate: college visible: 1920 x1080 @ 25 FPS
Thermal imaging: 256x192@25fps
*HDMI output preview audio and video, real-time display of traffic and abnormal temperature
*Built-in EMMC storage, can keep 100,000 temperature records, can use tools to export data to the PC
*Built-in white lamp fill light, support abnormal temperature sound alarm
*Small and exquisite, temperature - measuring door, advertising machine

Using Scene:
It can be widely used in the scene that needs to detect body temperature in a large range, such as stations, shopping malls, subway stations, schools and other places that need to quickly screen body temperature.

Model Parameter		KG-9268-TH
Model Parameter		2MP Thermal Camera for Person Temp. Measurement with HDMI output
Video	Sensor type	Silicon oxide uncooled infrared focal plane detector
	resolution	256x192, pixel size 12μm
	lens	Focal length: 3.2mm, field Angle: 56°x 42
	Temperature measurement accuracy	±0.3ºC, the target temperature is 35ºC~38ºC
	Temperature measuring distance	1 meter -- 5 meters
	Black body calibration	support
	Image sensor	1/2.8" 2.0M Pixel Progressive Scan CMOS
	Minimum illuminance	0.05Lux@F1.2 (color mode), 0.01Lux@F1.2 (black and white mode)
	Wide dynamic range	80 db or higher
	Signal-to-noise ratio	≥46dB (AGC OFF)
	Focal length	4mm
	Field Angle	The horizontal Angle of view is 84° and the vertical Angle of view is 45°
AI	Face capture	Built-in deep learning AI algorithm, supporting simultaneous detection of 20 faces, face detection, capture
AI	Abnormal temperature alarm	Voice alarm of abnormal body temperature (default alarm threshold is 37.3ºC)
	Power interface	DC12V
	Network interface	1 10/100BaseT Ethernet with RJ45 port
	Alarm interface	Support switch alarm signal output, can link external sound and light alarm
	Audio video interface	Supports 1 HDMI HD audio and video output
	storage	Built-in EMMC storage, can store up to 100,000 temperature records
	Operating temperature	-10ºC~35ºC
	Working humidity	0%-90% RH (Condensation free )
	Protection class	IP64
	Power supply	12VDC
	Power consumption	≤5W (Do not turn on the fill light)
	Product size	162mm86mm77mm
	weight	<1kg
